Sparkler Filter Press Machine – Industrial Liquid Filtration Solution
A Sparkler Filter Press Machine is a high-efficiency filtration system designed for removing fine suspended particles from liquids. It is widely used in industries such as pharmaceuticals, chemicals, food & beverages, edible oil, cosmetics, and beverages where clarity and purity are critical.
Key Features
Closed Filtration System – Ensures contamination-free operation
High Filtration Efficiency – Removes fine particles using filter sheets
SS304 / SS316 Construction – Suitable for hygienic and corrosive applications
Multi-Plate Design – Higher filtration area for increased output
Easy Operation & Maintenance – Quick dismantling and cleaning
Pressure Filtration – Uniform flow and consistent clarity
Working Principle
The liquid is pumped into the filter press where it passes through multiple filter sheets mounted between plates. Solid impurities are trapped within the sheets, and clear filtrate is collected at the outlet.
Applications
Edible oil filtration
Pharmaceutical liquids and syrups
Chemicals and solvents
Beverages (juice, soft drinks)
Cosmetics and herbal extracts
Technical Specifications (Typical)
Filtration Area: 1 m² to 20 m² (customizable)
Number of Plates: 5 to 40 plates
Flow Rate: Up to 10,000 LPH (depending on model)
Material of Construction: SS304 / SS316
Operating Pressure: Up to 4–6 kg/cm²
Advantages
Compact and space-saving design
Low operational cost
High clarity output
Suitable for batch processing
Masterly Engineering India Pvt. Ltd.
Leading manufacturer and exporter of Sparkler Filter Press Machines with robust design, high efficiency, and customized solutions as per client requirements.
