Ribbon Blender Manufacturer and Exporter in Faridabad Haryana India , we have customer using our machinery across world
we are manufacturer of Industrial Mixer like Ribbon Blender, Paddle Mixer, Double Cone Blender, Octagonal Blender etc.
Capacity from 5 Liter to 25000 liter
if you are looking mixer , Vibro Sifter, or conveyors
contact us today
Masterly Engineering India Pvt Ltd.
+91 9899643853
MRB-3KL
3000L
1200L-1800L
33
15KW(20 HP)
MRB-4KL
4000L
1600L-2400L
33
22KW(30HP)
MRB-5KL
5000L
2000L-3000L
26
30KW(41HP)
MRB-6KL
6000L
2400L-3600L
26
37KW(50HP)
MRB-8KL
8000L
3200L-4800L
26
37 KW(50HP)
MRB-10KL
10000L
4000L-6000L
20
45 KW(61HP)
VRB-12KL
12000L
4800L-7200L
20
45 KW(61HP)
VRB-15KL
15000L
6000L-9000L
17
55KW(75HP)
www.masterlyindia.com
(http://masterlyindia.com/?page_id=2599)
www.masterlyindia.com
Advantages of Horizontal Ribbon Blender
Mild mixing which will not break the physical size of material
More loading factor: ribbon blender’s working volume is between 40%-70% of the total nominal volume, but generally speaking, 60% is maximum loading ratio of ribbon blender when mix heavy bulk density material
Easy Cleaning: usually, the opening at ribbon blender’s top cover is very large to touch into the inner surface for cleaning purpose.
Easy Maintenance: the structure of ribbon blender is very simple, easy to dismantle and maintenance
Low Power Energy……
Additionally: we can build to custom sizes for particular batch sizes, as well as larger blenders up to 20000 Liter (Non-standard sizes increases build time and cost)
Construction Material:
All of our standard series ribbon blenders are manufactured in 304 Stainless Steel. SS304 meets food grade requirements; and offers exceptional resistance to corrosion, wear and tear, and ensures a long life and the value of your equipment. For certain applications where high levels of corrosive agents are present, we can manufacture in T316 Stainless Steel.
Agitators:
The name sake of Masterly ribbon blenders feature double helical ribbon agitators fit to a solid stainless steel shaft. We also offer paddle style agitators, as well as ribbon mixers with scraper blades.
Drive Motors:
Masterly Blenders utilize direct drive style gear motors to power our equipment. Direct drive systems have proven highly reliable and require less maintenance than traditional chain drive systems. Our standard drive motors offer a service factor for continual mixing throughout the day. Based on the capacity of your equipment we offer a drive motor consistent for normal mixing conditions; although we can modify this to higher powered equipment, different RPM and variable speed drive systems if requested.
www.masterlyindia.com
(http://masterlyindia.com/?page_id=2599)
www.masterlyindia.com
Shaft Seals
Our ribbon blenders come standard with our Masterly packing glands. Packing glands feature a Teflon style rope which is compressed against the end plate, creating a barrier to keep the mixing product in the trough. These work very well for both dry and wet mixing applications.
As an upgrade for your blender we also offer air purged seals for powders or slurry mixes. These air seals are ideal for scenarios requiring caustic wash downs and sanitary requirements. These seals are easy to disassemble for regular cleaning and offer years of service.
Discharge system
Based on your mixing requirements your blender can be fitted with different styles of discharge systems. Our most common style discharge is a butterfly valve, which works well in wet mixing solutions as well as dry. For dry mixing we offer the Masterly slide gate in manually operated or pneumatically actuated. The benefit of our slide gate system is zero ‘dead spot’ in the mix.
Our blender’s standard height is to set the discharge 40” from the ground, allowing for a pallet and barrel below the equipment. This height can be increased or decreased based on your needs.
Covers
Our blenders come standard with hand open lids. As an optional feature, we can add a pneumatic cylinder for lifting.
Masterly Company can also build a Masterly vent-a-hood system or a custom model to your designs.
Safety Systems
Masterly ribbon blenders are built with safety as our highest priority. Masterly ribbon blenders standard is to include ALL of our available safety equipment. These systems include micro switches to prevent the agitator from turning when the lid is open. We also offer safety grates on the top and discharge. All safety labeling is standard as well on Masterly equipment.
Stands/Heights Mounting of Ribbon Blender: We offer Customized Stand/Mounting Legs/Systems.
Request a quotation
To request a quotation on a Masterly Ribbon Blender
Please email sales@masterlyindia.com
We welcome a phone: Call at +91 9899643853
www.masterlyindia.com
(http://masterlyindia.com/?page_id=2599)
www.masterlyindia.com
Ribbon Blenders and Mixers for Sale
Sometimes the speed of business demands immediate solutions. We carry a range of pre-built units in some of our most popular sizes. These units are ready for immediately delivery and can be up and running at your facility in a short time. This inventory fluctuates, so please check back often or call us at +91 9899643853 to check on the latest availability.
Stainless Steel Ribbon Blender In manufacturing 2-3 weeks to completion
Description:
300 Liter stainless steel ribbon blender
Price:
Please call, based on options
Material:
304 Stainless Steel
Unit Capacity:
300 L
Agitator Style:
Spiral Ribbon with solid stainless steel shaft
Cooking Jacket:
No
Drive Motor:
Customizable
Trough Dimensions
ND
Discharge Style:
Customizable
Discharge Height:
Customizable
