Co-Mill (Conical Mill) – 1 HP
Technical Specifications
General

Machine Type: Co-Mill / Conical Mill

Motor Power: 1 HP (0.75 kW)

Motor Speed: 1440 RPM (standard)

Operating Speed: 800–1200 RPM (via pulley / VFD optional)

Output Capacity: 50–150 kg/hr (depends on material & sieve size)

Construction

Product Contact Parts: SS 304 / SS 316

Non-Contact Parts: MS with epoxy / powder coating

Rotor Type: Conical rotor with knives

Screen Type: Perforated / slotted screen (changeable)

Mechanical Details

Feeding Type: Manual gravity feed

Discharge Type: Bottom discharge

Sieve Size Range: 0.5 mm to 5 mm

Drive Type: Belt driven / direct drive

Bearings: Sealed, heavy-duty

Electrical

Power Supply: 415 V, 3 Phase, 50 Hz

Starter: DOL / Star-Delta / VFD (optional)

Control Panel: On-off push button / VFD panel (optional)

Safety & Compliance

Interlock: Screen & lid safety interlock (optional)

Dust Control: Closed design for minimum dust

GMP Design: Yes (for pharma grade)

Dimensions & Weight (Approx.)

Machine Height: 900–1100 mm

Footprint: 600 × 600 mm

Weight: 120–150 kg

Applications

Granulation sizing

De-lumping powders

Wet & dry granulation

Spices, chemicals, food powders, pharma granules
